Giesse GS-HD Side-hung Arm – Type M - Hinges

Product manufacturer

Product Category

Hinges

Giesse Hinges GS-HD Side-hung Arm – Type M

GS-HD Type M side-hung arms are designed for small to medium-sized windows for medium/low load applications. Tested for durability and smooth operation. Suitable for aluminium window systems with 18 mm groove. Provides opening angle up to 87° (70° for 8" size)

Code: 08201, 08202, 08195, 08196, 08197, 08198
Bag Width: 18 mm
Sash Frame Distance: 13.5 (+0.5 tolerance) mm
Arm Length: 214, 270, 310, 358, 412, 459 mm

Loading specs...

Suppliers & Dealers

0 dealers found

Applicators & Contractors

0 installers found

More Products fromGiesse

GS-HD Side-hung Arm – Type A

Giesse

₹1,600

GS-HD Side-hung Arm – Type C

Giesse

₹2,500

GS-HD Type C Plus Super – Self-Balancing Side-hung Arm

Giesse

₹3,100

GS-HD Type TS – Multi-Position Side & Top Hung Arm

Giesse

₹2,800

GS-HD Limitation Arm – Side Hung (Friz / With Lock)

Giesse

₹1,050

MECHANISM – One-way Fasteners (Side-hung)

Giesse

₹500

Services & Tools

Comprehensive services and tools to support your Hinges project needs

No active Tools & Services currently

Product Comparison

Complete Technical Specifications for Giesse GS-HD Side-hung Arm – Type M

Property	Value	Unit
Code	08201, 08202, 08195, 08196, 08197, 08198	—
Bag Width	18	mm
Sash Frame Distance	13.5 (+0.5 tolerance)	mm
Arm Length	214, 270, 310, 358, 412, 459	mm
Maximum Sash Opening angle	70, 87	°
Max Height	1200	mm
Max Width	550, 600, 650	mm
Max Weight	15, 16, 17, 20, 21	Kg
