Giesse Hinges GS-HD Type C Plus Super – Self-Balancing Side-hung Arm

GS-HD Type C Plus Super are self-balancing side-hung arms (one right and one left) designed for medium-sized and heavier outward opening casement windows. These arms provide improved load distribution and smooth operation for higher sash weights. Suitable for aluminium window systems requiring enhanced performance and stability.

Code: 08232, 08233, 08234, 08235, 08236
Bag Width: ~23 mm
Sash Frame Distance: 16.5 (+0.5 tolerance) mm
Arm Length: 327.5, 373.5, 425.5, 474.5, 523.5 mm

Loading specs...

Suppliers & Dealers

0 dealers found

Applicators & Contractors

0 installers found

More Products fromGiesse

GS-HD Side-hung Arm – Type A

Giesse

₹1,600

GS-HD Side-hung Arm – Type M

Giesse

₹1,350

GS-HD Side-hung Arm – Type C

Giesse

₹2,500

GS-HD Type TS – Multi-Position Side & Top Hung Arm

Giesse

₹2,800

GS-HD Limitation Arm – Side Hung (Friz / With Lock)

Giesse

₹1,050

MECHANISM – One-way Fasteners (Side-hung)

Giesse

₹500

Services & Tools

Comprehensive services and tools to support your Hinges project needs

No active Tools & Services currently

Product Comparison

Complete Technical Specifications for Giesse GS-HD Type C Plus Super – Self-Balancing Side-hung Arm

Property	Value	Unit
Code	08232, 08233, 08234, 08235, 08236	—
Bag Width	~23	mm
Sash Frame Distance	16.5 (+0.5 tolerance)	mm
Arm Length	327.5, 373.5, 425.5, 474.5, 523.5	mm
Maximum Sash Opening angle	82, 85, 87	°
Max Height	1600	mm
Max Width	500, 650, 750, 800	mm
Max Weight	32, 38, 40, 42, 45	Kg
